In Figure
(leaf switches). NM2-36P represents a Sun Datacenter InfiniBand Switch 36 (spine
switch).
In this configuration, four up-links from the gateway switch (leaf switch) are cabled to
the Sun Datacenter InfiniBand Switch 36 (spine switches). Each leaf switch is
connected to each spine switch.
A.9 Connecting an Exalogic Half Rack and an Exalogic Full
Rack
Figure A-9
the same InfiniBand fabric.
Figure A-9
In Figure
(leaf switches). NM2-36P represents a Sun Datacenter InfiniBand Switch 36 (spine
switch).
In this configuration, six up-links from the gateway switch (leaf switch) are cabled to
the Sun Datacenter InfiniBand Switch 36 (spine switches). Each leaf switch is
connected to each spine switch.
A.10 Connecting Two Exalogic Full Racks
Figure A-10
InfiniBand fabric.
A-8, NM2-GW represents a Sun Network QDR InfiniBand Gateway Switch
illustrates how an Exalogic half rack is connected to an Exalogic full rack on

Exalogic Half Rack and Exalogic Full Rack

A-9, NM2-GW represents a Sun Network QDR InfiniBand Gateway Switch
illustrates how two Exalogic full racks are connected on the same

Connecting an Exalogic Half Rack and an Exalogic Full Rack

Appendix A
A-7
