8.3

Parts list

No. Qty. Description
A 1 Main Frame
A1 1 Sensor Wire 1500Mm
A2 1 Motor
A2-1 2 Motor-Screw
A3 1 Tension Cable
A3-1 1 Spring
A4 1 Dc Line 350Mm
A5 1 Sensor Wire 350Mm
A5-1 2 Sensor Screw
A6 1 Flywheel
A7 1 Axle
A8 1 Bearing 6000Z
A8-1 1 Bearing 6300Z
A9 1 Bush M10x14x9t
A10 4 Nut M10
A11 2 Flange Nut M8
A12 1 Magnetic Housing
A13 1 Bolt M6x55l
A14 1 Nut M6
A15 1 Washer M6x19x1.5t
A16 1 Washer M6x14x1.2t
A17 1 Nylon Nut M6
A18 1 Bolt M8x45l
A19 1 Washer M8
A20 1 Nylon Nut M8
A21 1 Pressing Tagger
A22 1 Spring
A23 1 Bolt M8x20l
A24 1 Washer M8x22x1t
A25 1 Nylon Nut M8
A26 1 Pressing Pully
34
No. Qty. Description
A27 1 Nylon Nut
A28 1 Belt
A29 1 Driving Pully
A30 1 Magnetic
A31 1 Crank Axle
A32 4 Bolt M6x16l
A33 4 Spring Washer M6
A34 4 Nylon Nut M6
A35 2 Bearing 6004Zz
A36 2 C-Clip
A37 2 Crank
A38 2 Flange Nut M10
A39 2 Plate Cover
A39-1 6 Screw
A39-2 6 Washer
A40 2 Plastic Cover
A41 2 C-Clip
A42 2 Bearing 2203Zz
A43 2 Bolt M8
A44 2 End Cap
A45 1 Left Chain Cover
A46 1 Right Chain Cover
B 1 Central Support Tube
B1 1 Sensor Wire 900Mm
B2 1 Hand Pulse Wire 650Mm
B3 2 End Cap
B4 1 End Plug
C 1 Rear Stabilizer
C1 2 End Cap
D 1 Front Stabilizer
D1 2 End Cap
EX20
