Specifications

6.4.13 Ambient Conditions

Enclosure
Enclosure kit available
Vibration test
Maximum relative humidity
Aggressive environment (IEC 60721-3-3), coated (standard) frame H1–H5
Aggressive environment (IEC 60721-3-3), non-coated frame H6–H10
Aggressive environment (IEC 60721-3-3), coated (optional) frame H6–H10
Aggressive environment (IEC 60721-3-3), non-coated frame I2–I8
Test method according to IEC 60068-2-43 H2S (10 days)
Ambient temperature 1)
Minimum ambient temperature during full-scale operation
Minimum ambient temperature at reduced performance
Minimum ambient temperature at reduced performance
Temperature during storage/transport
Maximum altitude above sea level without derating
Maximum altitude above sea level with derating
Derating for high altitude, see chapter 6.3.2 Derating for Low Air Pressure and High Altitudes
Safety standards
EMC standards, Emission
EMC standards, Immunity
Energy efficiency class
1) Refer to special conditions in the design guide for:
•
Derating for high ambient temperature
•
Derating for high altitude
2) Determined according to EN50598-2 at:
•
Rated load
•
90% rated frequency
•
Switching frequency factory setting
•
Switching pattern factory setting
MG18A602
Quick Guide
5%-95% (IEC 60721-3-3; Class 3K3 (non-condensing) during operation
See maximum output current at 40/50 °C in chapter 6.1.2 3x380–480 V AC
EN 61800-3, EN 61000-3-12, EN 61000-6-1/2, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4,
Danfoss A/S © 08/2014 All rights reserved.
EN/IEC 61800-5-1, UL 508C
EN 61800-3, EN 61000-6-3/4, EN 55011, IEC 61800-3
EN 61000-4-5, EN 61000-4-6
IP20, IP54
IP21, TYPE 1
1.0 g
Class 3C3
Class 3C2
Class 3C3
Class 3C2
0 °C
-20 °C
6
-10 °C
-30 to +65/70 °C
1000 m
3000 m
IE2
