Installation
I4 enclosure
3
3
1 RS-485
2 Mains
3 Ground
4 Cable clamps
5 Motor
6 UDC
7 Relays
8 I/O
Illustration 3.15 I4 Enclosure
IP54, 380-480 V, 0.75-4.0 kW (1-5 HP)
Illustration 3.16 IP54 I2-I3-I4 Enclosure
16
Quick Guide
I6 enclosure
Illustration 3.17 Connecting to Mains for I6 Enclosure
IP54, 380-480 V, 22-37 kW (30-50 HP)
Illustration 3.18 Connecting to Motor for I6 Enclosure
IP54, 380-480 V, 22-37 kW (30-50 HP)
Danfoss A/S © 08/2014 All rights reserved.
MG18A602
