Specifications

8.4 Ambient Conditions

Environment
Enclosure
Vibration test
Maximum THD
Maximum relative humidity
Aggressive environment (IEC 60068-2-43) H
Ambient temperature
Minimum ambient temperature during full-scale operation
Minimum ambient temperature at reduced performance
Temperature during storage/transport
Maximum altitude above sea level without derating
EMC standards, Emission
EMC standards, Immunity
Energy efficiency class
1) See special conditions in the design guidefor:
•
Derating for high ambient temperature.
•
Derating for high altitude.
8 8
2) Determined according to EN 50598-2 at:
•
Rated load.
•
90% rated frequency.
•
Switching frequency factory setting.
•
Switching pattern factory setting.

8.5 Cable Specifications

Cable lengths and cross-sections for control cables
Maximum motor cable length, shielded
Maximum motor cable length, unshielded
Maximum cross-section to control terminals, flexible/rigid wire without cable end sleeves
Maximum cross-section to control terminals, flexible wire with cable end sleeves
Maximum cross-section to control terminals, flexible wire with cable end sleeves with collar
Minimum cross-section to control terminals
1) For power cables, see electrical tables in chapter 8.1 Electrical Data.

8.6 Control Input/Output and Control Data

Digital inputs
Programmable digital inputs
Terminal number
Logic
Voltage level
Voltage level, logic 0 PNP
Voltage level, logic 1 PNP
Voltage level, logic 0 NPN
Voltage level, logic 1 NPN
Maximum voltage on input
Pulse frequency range
(Duty cycle) minimum pulse width
Input resistance, R
1) Terminals 27 and 29 can also be programmed as output.
44
v
S test
2
1)
2)
2)
2)
i
Danfoss A/S © 05/2018 All rights reserved.
®
VLT AutomationDrive FC 301/302
IP20/Chassis, IP21/Type 1, IP55/Type 12, IP66/Type 4X
5–93% (IEC 721-3-3; Class 3K3 (non-condensing) during operation
Maximum 50 °C (122 °F) (24-hour average maximum 45 °C (113 °F))
1)
1)
-25 to +65/70 °C (-13 to +149/158 °F)
1000 m (3280 ft)
FC 301: 50 m (164 ft)/FC 302: 150 m (492 ft)
FC 301: 75 m (246 ft)/FC 302: 300 m (984 ft)
1.5 mm
1 mm
0.5 mm
0.25 mm
1)
FC 301: 4 (5)
18, 19, 27
Approximately 4 kΩ
1.0 g
10%
Class Kd
0 °C (32 °F)
-10 °C (14 °F)
EN 61800-3
EN 61800-3
IE2
2
/16 AWG
2
/18 AWG
2 /20 AWG
2 /24 AWG
1)
/FC 302: 4 (6)
1) 1)
, 29 , 32, 33
PNP or NPN
0–24 V DC
<5 V DC
>10 V DC
>19 V DC
<14 V DC
28 V DC
0–110 kHz
4.5 ms
MG33AT02
