Danfoss FC 101 Quick Manual page 34

Programming
Parameter
0-03 Regional Settings
0-06 GridType
1-00 Configuration Mode
4 4
1-10 Motor Construction
1-20 Motor Power
1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor Nominal Speed
32
Quick Guide
Range
[0] International
[1] US
[0] -[[132] see start -up wizard
for open loop application
[0] Open loop
[3] Closed loop
*[0] Asynchron
[1] PM, non-salient SPM
[2] PM, salient IPM, non Sat.
[3] PM, salient IPM, Sat.
0.09–110 kW
50–1000 V
20–400 Hz
0–10000 A
50–9999 RPM
Danfoss A/S © 08/2014 All rights reserved.
Default Usage
0 –
Size selected Select operating mode for restart upon
reconnection of the frequency converter to
mains voltage after power down.
0 –
[0] Asynchron Setting the parameter value might change
these parameters:
1-01 Motor Control Principle
1-03 Torque Characteristics
1-14 Damping Gain
1-15 Low Speed Filter Time Const.
1-16 High Speed Filter Time Const.
1-17 Voltage filter time const.
1-20 Motor Power [kW]
1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor Nominal Speed
1-26 Motor Cont. Rated Torque
1-30 Stator Resistance (Rs)
1-33 Stator Leakage Reactance (X1)
1-35 Main Reactance (Xh)
1-37 d-axis Inductance (Ld)
1-38 q-axis Inductance (Lq)
1-39 Motor Poles
1-40 Back EMF at 1000 RPM
1-44 d-axis Inductance Sat. (LdSat)
1-45 q-axis Inductance Sat. (LqSat)
1-46 Position Detection Gain
1-48 Current at Min Inductance for d-axis
1-49 Current at Min Inductance for q-axis
1-66 Min. Current at Low Speed
1-72 Start Function
1-73 Flying Start
4-14 Motor Speed High Limit [Hz]
4-19 Max Output Frequency
4-58 Missing Motor Phase Function
14-65 Speed Derate Dead Time Compensation
Size related Enter the motor power from the nameplate
data.
Size related Enter the motor voltage from the nameplate
data.
Size related Enter the motor frequency from the
nameplate data.
Size related Enter the motor current from the nameplate
data.
Size related Enter the motor nominal speed from the
nameplate data.
MG18A602
