Warnings and Alarms
Fault Alarm/ Fault text
number warning bit
number
57 – AMA timeout
58 – AMA internal
59 25 Current limit
60 44 External Interlock
Heat sink
66 26
Temperature Low
69 1 Pwr. Card Temp
Illegal FC configu-
70 36
ration
Illegal power
79 – section configu-
ration
80 29 Drive initialised
87 47 Auto DC Braking
95 40 Broken Belt
126 – Motor Rotating
200 – Fire Mode
Fire Mode Limits
202 –
Exceeded
250 – New sparepart
251 – New Typecode
Table 5.1 Warnings and Alarms
MG18A602
Quick Guide
Warning Alarm Trip Cause of problem
locked
Try to start the AMA again a number of times, until the AMA
is carried out.
NOTICE
– X –
Repeated runs may heat the motor to a level where
the resistance Rs and Rr are increased. In most cases,
however, this is not critical.
X X – Contact the local Danfoss supplier.
X – – The current is higher than the value in 4-18 Current Limit.
External interlock has been activated. To resume normal
operation, apply 24 V DC to the terminal programmed for
– X – external interlock and reset the frequency converter (via
serial communication, digital I/O, or by pressing reset button
on keypad).
This warning is based on the temperature sensor in the IGBT
X – –
module (on 400 V, 30–90 kW (40–125 HP) and 600 V units).
The temperature sensor on the power card exceeds the
X X X
upper or lower limits.
– X X
The control card and power card are not matched.
X X –
Internal fault. Contact the local Danfoss supplier.
– X – All parameter settings are initialised to default settings.
X – The drive is auto DC braking.
Torque is below the torque level set for no load, indicating a
X X –
broken belt. See parameter group 22-6* Broken Belt Detection.
– X – High back-emf voltage. Stop the rotor of the PM motor.
X – – Fire mode has been activated.
Fire Mode has suppressed one or more warranty voiding
X – –
alarms.
The power or switch mode power supply has been
– X X exchanged (on 400 V, 30-90 kW (40-125 HP) and 600 V units).
Contact the local Danfoss supplier.
The frequency converter has a new type code (on 400 V,
– X X 30-90 kW (40-125 HP) and 600 V units). Contact the local
Danfoss supplier.
