Installation
I2 enclosure
1
2
3
1 RS-485
2 Mains
3 Ground
4 Cable clamps
5 Motor
6 UDC
7 Relays
8 I/O
Illustration 3.13 I2 Enclosure
IP54, 380-480 V, 0.75-4.0 kW (1-5 HP)
MG18A602
Quick Guide
I3 enclosure
8
7
6
5
4
1 RS-485
2 Mains
3 Ground
4 Cable clamps
5 Motor
6 UDC
7 Relays
8 I/O
Illustration 3.14 I3 Enclosure
IP54, 380-480 V, 5.5-7.5 kW (7.5-10 HP)
Danfoss A/S © 08/2014 All rights reserved.
3
3
15
