Danfoss FC 101 Quick Manual page 30

Programming
Parameter
1-10 Motor Construction
4 4
1-20 Motor Power
1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor Nominal Speed
1-26 Motor Cont. Rated Torque
1-29 Automatic Motor Adaption (AMA) See 1-29 Automatic Motor
1-30 Stator Resistance (Rs)
28
Quick Guide
Option
*[0] Asynchron
[1] PM, non-salient SPM
[2] PM, salient IPM, non Sat.
[3] PM, salient IPM, Sat.
0.12–110 kW/0.16–150 hp
50.0–1000.0 V
20.0–400.0 Hz
0.01–10000.00 A
50.0–9999.0 RPM
0.1–1000.0
Adaption (AMA)
0.000–99.990
Danfoss A/S © 08/2014 All rights reserved.
Default Usage
[0] Asynchron Setting the parameter value might change
these parameters:
1-01 Motor Control Principle
1-03 Torque Characteristics
1-14 Damping Gain
1-15 Low Speed Filter Time Const.
1-16 High Speed Filter Time Const.
1-17 Voltage filter time const.
1-20 Motor Power [kW]
1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor Nominal Speed
1-26 Motor Cont. Rated Torque
1-30 Stator Resistance (Rs)
1-33 Stator Leakage Reactance (X1)
1-35 Main Reactance (Xh)
1-37 d-axis Inductance (Ld)
1-38 q-axis Inductance (Lq)
1-39 Motor Poles
1-40 Back EMF at 1000 RPM
1-44 d-axis Inductance Sat. (LdSat)
1-45 q-axis Inductance Sat. (LqSat)
1-46 Position Detection Gain
1-48 Current at Min Inductance for d-axis
1-49 Current at Min Inductance for q-axis
1-66 Min. Current at Low Speed
1-70 PM Start Mode
1-72 Start Function
1-73 Flying Start
4-14 Motor Speed High Limit [Hz]
4-19 Max Output Frequency
4-58 Missing Motor Phase Function
14-65 Speed Derate Dead Time Compensation
Size related Enter the motor power from the nameplate
data.
Size related Enter the motor voltage from the nameplate
data.
Size related Enter the motor frequency from the
nameplate data.
Size related Enter the motor current from the nameplate
data.
Size related Enter the motor nominal speed from the
nameplate data.
Size related This parameter is available when 1-10 Motor
Construction is set to options that enable
permanent motor mode.
NOTICE
Changing this parameter will affect the
settings of other parameters.
Off Performing an AMA optimizes motor
performance.
Size related Set the stator resistance value.
MG18A602
