Introduction

1 Introduction

1.1 Purpose of the Quick Guide

The quick guide provides information for safe installation
and commissioning of the frequency converter.
The quick guide is intended for use by qualified personnel.
Read and follow the quick guide to use the frequency
converter safely and professionally, and pay particular
attention to the safety instructions and general warnings.
Keep this quick guide available with the frequency
converter at all times.
®
VLT is a registered trademark.

1.2 Additional Resources

•
®
VLT HVAC Basic Drive FC 101 Programming Guide
provides information on how to programme and
includes complete parameter descriptions.
•
®
VLT HVAC Basic Drive FC 101 Design Guide
provides all technical information about the
frequency converter and customer design and
applications. It also lists options and accessories.
The technical documentation is available in electronic form
on the documentation CD that is shipped with the
product, or in print at the local Danfoss sales office.
MCT 10 Set-up Software Support
Download the software from http://www.danfoss.com/
BusinessAreas/DrivesSolutions/Software+MCT10/
MCT10+Downloads.htm.
During the installation process of the software, enter
access code 81463800 to activate FC 101 functionality. A
licence key is not required for using FC 101 functionality.
The latest software do not always contain the latest drive
updates. Contact the local sales office for the latest drive
updates (*.upd files), or download the drive updates from
www.danfoss.com/BusinessAreas/DrivesSolutions/
fc101driveupdates.

1.3 Document and Software Version

The Quick Guide is regularly reviewed and updated. All
suggestions for improvement are welcome.
Edition Remarks
MG18A6xx Replaces MG18A5xx
MG18A602
Quick Guide

1.4 Certificates and Approvals

Certification
EC Declaration of
Conformity
UL Listed
C-tick
Table 1.1 Certificates and Approvals
The frequency converter complies with UL508C thermal
memory retention requirements. For more information,
refer to the section Motor Thermal Protection in the
product specific design guide.

1.5 Disposal

Software version
2.70
Danfoss A/S © 08/2014 All rights reserved.
IP20
✓
✓
✓
Equipment containing electrical components
must not be disposed of together with domestic
waste.
It must be separately collected with electrical
and electronic waste according to local and
currently valid legislation.
