Chapter 1: Product Introduction

Rear Bottom

12V
DC Input
USB 3.0
HDMI
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
Line-out
LAN COM 1
Mic-in COM 2
12V DC Input
Used to plug a DC power cord.
HDMI Ports
HDMI ports used to connect HDMI interface monitors.
USB 3.0 Ports
USB 3.0 ports to connect the system with USB 3.0/2.0 devices.
LAN Ports
Dual Gigabit LAN port to connect the system to a local area network.
Line-out
Used to connect a headphone or a speaker.
Mic-in
Used to connect an external microphone.
COM1 and COM2
Serial ports to connect with compatible serial devices.
