Chapter 3: System Setup
Installing SO-DIMM Memory Modules
1. Locate the DIMM1 slot on the board.
SO-DIMM Slots
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
t2h.eInmseortdul e into the slot at an approximately 30 degree angle.
Push the module down until the clips on both sides of the slot lock into
position.
29
KPPC 1514B/1814B/2114B User Manual
