Chapter 1: Product Introduction
▪ 4 x USB 3.0
▪ 2 x HDMI (can only output either one of the HDMI ports)
▪ 1 x RS232
▪ 1 x RS232/422/485
▪ 1 x Line-out
▪ 1 x Mic-in
▪ 1 x 12V DC-in power jack
Mechanical & Environment
▪otIePcpti r on: IP65 panel front side
▪ Mounting: panel/wall/VESA 100mm x 100mm
▪ Operating temperature: 32°F to 113°F (0°C to 45°C)
▪ Storage temperature: -4°F to 140°F (-20°C to 60°C)
▪ Operating humidity: 10%~90% relative humidity, non-condensing
▪ Dimension:
– 417.80 (W) x 312.80 (H) x 66.25 (D) mm (KPPC 1514B)
– 490.80 (W) x 320.60 (H) x 65.15 (D) mm (KPPC 1814B)
– 562.40 (W) x 382.40 (H) x 65.35 (D) mm (KPPC 2114B)
▪ Weight:
– 7.44kg (KPPC 1514B)
– 8.0kg (KPPC 1814B)
– 9.9kg (KPPC 2114B)
OS Support List
▪i n dWows 10 IoT 64-bit
Certifications
▪ EMC & Safety
▪ CE/FCC Class A
