Chapter 3: System Setup
3. Connect the SATA data and power cables to the respective connectors
on the board and the other ends of the cables to the connectors on the
storage drive.
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
4. The image below marks the location of the mounting post used to
position the storage drive bracket to the system. Fix the bracket to this
mounting post.
31
KPPC 1514B/1814B/2114B User Manual
