Chapter 4: BIOS Setup
System Agent (SA) Configuration
Aptio Setup Utility - Copyright (C) 2017 American Megatrends, Inc.
Chipset
System Agent Bridge Name
Skylake
Memory Configuration
Memory Frequency
2133 MHz
Total Memory
16384 MB
DIMM#0
16384 MB
Not Present
DIMM#1
Max TOLUD
[Dynamic]
Max Link Speed
[Auto]
Graphics Configuration
Version 2.17.1255. Copyright (C) 2017 American Megatrends, Inc.
Max TOLUD
Configures the maximum value of TOLUD.
Max Link Speed
Configures the maximum link speed of the PEG device.
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
Graphics Configuration
Maximum Value of TOLUD.
Dynamic assignment would
adjust TOLUD automatically
based on largest MMIO length
of installed graphic controller
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Primary Display
Select which IGFX/PEG/PCI graphics device should be the primary display or
select SG for Switchable Gfx.
Primary IGFX Boot Display
Select the video device which will be activated during POST. Has no effect if
external graphics is present. Secondary boot display selection will appear
based on your selection. VGA modes will be supported only on primary display.
LVDS
Enables or disables LVDS.
LVDS Panel Type
Configures the LVDS panel resolution.
51
Aptio Setup Utility - Copyright (C) 2017 American Megatrends, Inc.
Chipset
Graphics Configuration
Primary Display
[Auto]
Primary IGFX Boot Display
[VBIOS Default]
[Enabled]
LVDS
[1024x768,18bit,60Hz]
LVDS Panel Type
Version 2.17.1255. Copyright (C) 2017 American Megatrends, Inc.
Select which of IGFX/PEG/PCI
Graphics device should be
Primary Display Or select SG
for Switchable Gfx.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
KPPC 1514B/1814B/2114B User Manual
