Chapter 2: Jumpers and Connectors
SPI Flash Programmable Connector
Connector type: 2x4 8-pin header
Connector location: BIOS_P
1 2
7 8
Pin
Definition
1
+3V_SPI
3
S_SPI_CS1#Q
5
S_SPI_MISO_2Q
7
NC
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
GND
4
S_SPI_CLK_2Q
6
S_SPI_MOSI_2Q
8
NC
Battery Connector
Connector type: 1x2 2-pin header
Connector location: BATTERY_H
2
1
Pin
Definition
1
+BAT
2
GND
23
KPPC 1514B/1814B/2114B User Manual
