Chapter 3: System Setup
Installing Expansion Cards
The mini PCIe connector supports full size and half size mini PCIe modules.
1. Before installing the modules, remove the I/O cover by opening the cable
ties and loosening the 3 screws on the bottom of the system.
Full Size Mini PCIe
Half Size Mini PCIe
36
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
KPPC 1514B/1814B/2114B User Manual
