Chapter 3: System Setup
Installing LGA1151 35W CPU
1 i t h . Wt h e chassis removed, locate the CPU socket and remove the protective
2. Unlock the socket by pushing the load lever down, moving it sideways
cap.
until it is released from the retention tab; then lift the load lever up.
CPU Socket
Protective Cap
33
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
KPPC 1514B/1814B/2114B User Manual
