i-on40
You can remove the output from Partition 1 by
pressing
<
Press or
u
to assign the output to each Partition as required.
>
Press when you have finished assigning outputs to
Y
Partitions.
4. Press n to scroll down to the next output.
Polarity
This option allows you to change the polarity of the wired
outputs. There are two options:
Normal
The output is held at +12V while inactive, and at 0V
when activated.
Inverted
The output is held at 0V while inactive, and at +12V
when activated.
To change the polarity of a wired output:
1. Select Outputs – Wired Outputs.
The bottom line of the display shows the first in the
list of four available wired outputs.
2. Press u or n to select the wired output that you wish
to change and press >.
The bottom line of the display shows the word
"Name".
3. Press n until the bottom line shows "Polarity", and
then press >.
The bottom line of the display shows the current
polarity.
4. Press > or < to change the polarity.
5. Press Y to store any changes to the polarity.

Plug-By Outputs

The plug-by outputs are designed for use by standalone
communicators (see i-on40 Installation Guide for
connection details). You can give each output a name, a
or to change the "Yes" to a "No".
>
to scroll to other Partitions. Press
n
Installer Mode Programming
or
<
Page 33
