Configuring the Boot
Volume on a Free
Capacity Node
Appendix A: Boot Device Installation
10. Click Next.
11. In the Specify Advanced Volume Parameters dialog, perform these steps:
a. From the Volume I/O characteristics area, select File System.
b. From the Preferred controller ownership area, select Slot A.
c. From the Volume-to-LUN Mapping area, select Map Later with Storage
Partitioning.
12. To create the volume and the volume group, click Finish.
The Create Volume Wizard – Creation Successful dialog appears.
13. Click No.
14. Click OK.
15. Use the Storage Partitioning premium feature to map the volume to the host that
uses LUN 0.
NOTE For additional information about how to map volumes that use Storage
Partitioning, refer to the online help topics in the Array Management Window.
"Ensuring a Single Path to the Storage
16. Go to
1. Right-click the Free Capacity node that you want to use, and click Create
Volume.
The Default Host Type dialog appears.
2. Select the default host type from the list, and click OK.
The Create Volume Wizard Introduction dialog appears.
3. Click Next.
The Specify Volume Parameters dialog appears.
4. Specify the boot volume capacity.
A capacity of 4 GB is recommended. The capacity must be at least 2 GB.
5. Name the volume to identify it as the boot volume.
6. From the Advanced Volume Parameters area, select Customize settings.
7. Click Next.
8. In the Specify Advanced Volume Parameters dialog, perform these steps:
a. From the Volume I/O characteristics area, select File System.
b. From the Preferred controller ownership area, select Slot A.
c. From the Volume-to-LUN Mapping area, select Map Later with Storage
Partitioning.
Array" on page 150.
149
