Silicon Graphics InfiniteStorage 4000 Series System Upgrade Manual page 142

134
10. Click Next.
The Choose Install Folder window appears, which identifies the default
installation location.
11. Click Next.
The Select Installation Type window appears.
12. The steps in this procedure describe a typical (full) installation. Based on the type
of installation you are performing, select one of these options.
NOTE If you want to install the Windows boot device on a storage array, select
Management Station. This selection installs the software on a storage management
station that is attached to the storage array where the boot device will be installed. Go
to Appendix A, "Boot Device Installation
procedures. After you finish the boot device installation procedures, return to this
procedure.
Typical (Full Installation) – This selection, which is the default, installs all
—
of the packages on the system. Choose this option if you do not know which
installation type to select.
Management Station – This selection installs the software that is needed to
—
configure, manage, and monitor a storage array. This option is for your
workstation or management computer.
Host – This selection installs the storage array server software. Use this type
—
of installation for the host (server) that is connected to the storage array
(Windows 2000 OS and Windows Server 2003 OS only).
Custom – This selection lets you customize the features to be installed.
—
The selected installation type is selected in blue text.
13. Click Next.
If the software already exists, the Overwrite Warning dialog appears.
14. If the Overwrite Warning dialog appears, click OK.
The Automatically Start Monitor? window appears.
15. Select the appropriate option for your system.
If you start the Event Monitor on multiple machines, you might receive duplicate
error messages from the same storage array. If you do not want to receive
duplicate error messages, start the Event Monitor on only one machine. It is
recommended that you run the Event Monitor on one machine that will run
continuously.
to complete the boot device installation
