Example:
To refresh the QCE.
Switch# configure terminal
Switch (config)# qos qce refresh

4.2.145 qos wred

Command:
qos wred queue <queue> min-th <min_th> mdp-1 <mdp_1> mdp-2 <mdp_2> mdp-3
<mdp_3>
qos
Quality of Service
wred
Weighted Random Early Discard
queue
Specify queue
<Queue : 0~5>
Specific queue or range
min-th
Specify minimum threshold
<MinTh : 0-100>
mdp-1
Specify drop probability for drop precedence level 1
<Mdp1 : 0-100>
Specific drop probability in percent
mdp-2
Specify drop probability for drop precedence level 2
<Mdp2 : 0-100>
Specific drop probability in percent
mdp-3
Specify drop probability for drop precedence level 3
<Mdp3 : 0-100>
Specific drop probability in percent
Default:
Usage Guide:
To configure the Weighted Random Early Detection
Example:
To configure the Weighted Random Early Detection (below table)
Specific minimum threshold in percent
Command Guide of WGSW-48040HP
-243-
