7.2.3 To View the System Configuration

You can view the system configuration information including the printhead
type, printer configuration and the current software version number at the
SYSTEM CONFIGURATION menu. To do this:
1.
2.
MP65492–1
At the CURRENT MESSAGE screen, press the [F4] function key to
display the SETUP menu.
Select Diagnostics Menu > System Configuration.
The SYSTEM CONFIGURATION menu is displayed:
SYSTEM CONFIGURATION
>
Head Type
Message Type
Messages Stored
SW Links
SW Version
PCB Issue
Configuration
Language Group
Figure 7-5 System Configuration Menu
With the exception of the Message Type option, this screen is for
viewing only; you cannot change any of the options.
This setting...
Head Type
Message Type
>
7 Quality
7 Flexible
16 Quality
16 Flexible
Messages Stored
135
Chapter 7: Diagnostics and Maintenance
: Ultima
: 26
: A
: v1.0.15
: 1
: SS
: Euro1
Does this...
Indicates the type of printhead fitted
to the printer.
Allows you to display the MESSAGE
TYPE menu, which lists the available
message types. The example below
shows a sample of the message types
available for the Ultima printhead
with a 2-line Standard Speed (SS)
configuration:
MESSAGE TYPE
Figure 7-6 Message Type Menu
Indicates the number of messages
currently stored.
