Summary of Contents for Linx 5900

  • Page 1 How To Create a Shift Code...

  • Page 2: Table Of Contents

    How To Create a Shift Code Contents 1 Introduction........................... 2 1.1 Health and Safety ........................2 2 Shift codes ............................ 3 2.1 Examples ..........................3 2.1.1 Example 1: Daily shift code .................... 3 2.1.2 Example 2: Weekly shift code ..................3 3 Shift Code Editor ..........................

  • Page 3: Introduction

    How To Create a Shift Code 1 Introduction This document describes how to set up shift codes for the 5900 and 7900 printers. You need a User Level C password to perform all the tasks that are described in this document.

  • Page 4: Shift Codes

    A shift code records the time or the day of the week during which a message was printed. You can use the shift code to help you identify each batch of products. The 5900 and 7900 printers can generate two types of shift code field—Daily or Weekly. These types are described below.

  • Page 5: Shift Code Editor

    How To Create a Shift Code 3 Shift Code Editor You use the Shift Code Editor to create a shift code. To access the Shift Code Editor from the Print Monitor page, press the Menu key. Then select Stores > Shift Code Store to display the Shift Code Store page.
  • Page 6 How To Create a Shift Code Press the Shift Cycle key to display the Shift Cycle page. 69281 Figure 5. Shift Cycle page Highlight the required type then press the OK key to return to the Shift Code Editor page. To insert the first item, press the Add key.
  • Page 7 How To Create a Shift Code If you selected a Weekly shift code, the option is available, as shown below. 69284 Figure 7. Add page: Weekly shift code For a Weekly shift code, select the Start Day option to display the Start Day page. 69293 Figure 8.
  • Page 8 How To Create a Shift Code To set the time at which the shift begins, select the Start Time option to display the Setup page. 69285 Figure 9. Setup page: time For the “Daily” example on page 3, the first Start Time is “06:00”. For the “Weekly” example, the Start Time for each day is “00:00”.
  • Page 9 How To Create a Shift Code The Add page shows you the information that you entered for the first item. The page for the Daily shift code is as follows. 69287 Figure 11. Add page: Daily shift code The page for the Weekly shift code is as follows. 69294 Figure 12.
  • Page 10 To save the shift code, press the Exit key. The printer displays the Save As page. 69290 Figure 15. Save As page The Linx 5900 & 7900 Quick Start Guide describes how you use the Save As page. Page 9 of 12 FA69353–2 English...

  • Page 11: Edit A Shift Code

    How To Create a Shift Code 3.2 Edit a shift code To edit an existing shift code, do the following. At the Print Monitor page, press the Menu key. Then select Stores > Shift Code Store. The printer displays the Shift Code Store page. 69291 Figure 16.
  • Page 12 How To Create a Shift Code To make other changes, move the cursor to highlight an item. The Edit key and the Delete key become available. 69296 Figure 18. Shift Code Editor page: ShiftCode1 Press the Delete key to delete the highlighted item. The printer displays a confirmation page.

  • Page 13: Manage Shift Codes

    The Copy option, the Rename option, and the Delete option are not described in this document. These options are like the options in the Message Store > Manage Messages page, which is described in the Linx 5900 & 7900 Quick Start Guide. Page 12 of 12 FA69353–2 English...

This manual is also suitable for:

7900
