M90S-4S User's Manual
3) Output setting (only available or effective on bypass mode and standby mode)
Interface
Output:
Volt: 230V Freq: 60Hz
CVCF: Enable
Xtreme Power Conversion Corporation
Description
1. Volt:
For 3-3 10K, 3-1 10K and 1-1 10K models:
208: Presenting the rated output voltage with 208Vac
220: Presenting the rated output voltage with 220Vac
230: Presenting the rated output voltage with 230Vac
240: Presenting the rated output voltage with 240Vac
The default value is 230Vac.
For 2-2 6K and 3-3 10K LV models:
100: Presenting the rated output voltage with 100Vac
110: Presenting the rated output voltage with 110Vac
115: Presenting the rated output voltage with 115Vac
120: Presenting the rated output voltage with 120Vac
127: Presenting the rated output voltage with 127Vac
The default value is 120Vac.
2. Freq:
50Hz: The output frequency is setting for 50Hz.
60Hz: The output frequency is setting for 60Hz. NOTE: CVCF should be enabled to
modify this item.
If CVCF is disabled, output frequency will be decided according to the latest normal
utility frequency. If it is within 46Hz and
54Hz, the output frequency will be 50.0Hz. If it is within 56Hz
and 64Hz, the output frequency will be 60.0Hz.
3. CVCF:
Enable or disable converter mode.
Enable: The output frequency will be fixed at 50Hz or 60Hz according to setting of
"Freq". The input frequency could be from 46Hz to 64Hz.
Disable: The output frequency will synchronize with the input frequency within
46~54 Hz for 50Hz system or within 56~64 Hz for 60Hz system.
NOTE: CVCF means Constant Voltage and Constant Frequency. It represents con-
verter mode.
The default setting is Disable.
