- Page 1 Xtreme Value Tower Series (XVT) User’s & Installation Manual Xtreme Power Conversion™ Corporation ...
-
Page 2: Table Of Contents
XVT‐600, XVT‐800, XVT‐1200, XVT‐1500 USER’S MANUAL UNINTERRUPTIBLE POWER SUPPLY (UPS) TABLE OF CONTENTS SAFETY INSTRUCTIONS .......................... 3 PRODUCT DESCRIPTION .......................... 5 DETERMINING THE POWER REQUIREMENTS OF YOUR EQUIPMENT ............ 7 HARDWARE INSTALLATION GUIDE ....................... 7 QUICKSTART SOFTWARE INSTALLATION GUIDE ................... 9 REPLACING THE BATTERY ........................... 14 DEFINITIONS FOR LED INDICATORS ...................... 15 ALARMS ............................... 15 TROUBLESHOOTING ............................ 16 SPECIFICATIONS ............................ 17 SHIPPING LIST .............................. 18 OBTAINING SERVICE .......................... 19 XTREME POWER CONVERSION™ (XPC) CORPORATION LIMITED WARRANTY ........... 20 [2] ... -
Page 3: Safety Instructions
XVT‐600, XVT‐800, XVT‐1200, XVT‐1500 USER’S MANUAL UNINTERRUPTIBLE POWER SUPPLY (UPS) SAFETY INSTRUCTIONS ATTENTION: To safely interact with and enjoy all the features and benefits of these Xtreme Power Conversion Uninterruptible Power Supplies (UPS), please read and follow all installation and operation instructions completely. These UPS are designed to provide power protection for connected electronic equipment. Please read this manual before installing the XVT‐Series UPS models XVT‐600, XVT‐800, XVT‐1200, and XVT‐1500 as it provides important information that should be followed during installation and maintenance of the UPS and batteries, allowing you to correctly set up your system for the maximum safety and performance. Included is information on customer support and factory service, if it is required. If you experience a problem with the UPS, please refer to the Troubleshooting section in this manual to correct the problem. If the problem is not corrected, please collect information so that the Technical Support personnel can more effectively assist you. ... - Page 4 XVT‐600, XVT‐800, XVT‐1200, XVT‐1500 USER’S MANUAL UNINTERRUPTIBLE POWER SUPPLY (UPS) IMPORTANT SAFETY INSTRUCTIONS: (SAVE THESE INSTRUCTIONS) This manual contains important safety instructions. Please read and follow ALL instructions carefully during the installation and operation of the UPS. Read this manual thoroughly before attempting to unpack, install, or operate. CAUTION! To prevent the risk of fire or electric shock, install in a temperature and humidity controlled ...
-
Page 5: Product Description
XVT‐600, XVT‐800, XVT‐1200, XVT‐1500 USER’S MANUAL UNINTERRUPTIBLE POWER SUPPLY (UPS) PRODUCT DESCRIPTION UPS Functionality: The XVT UPS products use Line‐Interactive Automatic Voltage Regulation (AVR) UPS technology. Under normal AC power operation, the input power flows through the AVR circuit, regulating the incoming AC power to the output of the UPS and the load connected. If the input power disappears, the Inverter circuit is switched on to provide output from the batteries contained within the UPS. ... - Page 6 XVT‐600, XVT‐800, XVT‐1200, XVT‐1500 USER’S MANUAL UNINTERRUPTIBLE POWER SUPPLY (UPS) Battery/Surge Outlets: Provides battery‐powered/surge outlets for the connected equipment, and insures uninterruptible operation of your equipment during a power failure. Power Switch: Can be used as a master on/off switch for equipment connected to the battery‐ powered outlets. Power On Indicator: This LED is illuminated when the utility condition is normal and the UPS outlets are providing power, free of surges and spikes. Circuit Breaker: The circuit breaker that provides overload and fault protection. USB: Port/protocol that provides communication between the UPS and PC Network. [6] ...
-
Page 7: Determining The Power Requirements Of Your Equipment
XVT‐600, XVT‐800, XVT‐1200, XVT‐1500 USER’S MANUAL UNINTERRUPTIBLE POWER SUPPLY (UPS) DETERMINING THE POWER REQUIREMENTS OF YOUR EQUIPMENT 1. Make sure the total Volt‐Amp (VA) requirements of your connected equipment does not exceed the maximum VA rating for the UPS. The maximum VA ratings are shown in the Specifications section of this document. 2. Ensure that the equipment plugged into the battery‐powered outlets does not exceed the UPS rated capacity. If UPS rated capacities are exceeded, an overload condition may occur and cause the UPS to shut down and trip the circuit breaker. 3. If the power requirements of your equipment are listed in values other than Volt‐Amps (VA), convert Watts (W) or Amps (A) into VA by doing the calculations below. Note: The equation below ... - Page 8 XVT‐600, XVT‐800, XVT‐1200, XVT‐1500 USER’S MANUAL UNINTERRUPTIBLE POWER SUPPLY (UPS) 4. Depress the power switch to turn the UPS on. The power on LED indicator, and charging LED will illuminate after the UPS initial test to indicate the UPS is switched “ON”. 5. If an overload is detected, an audible alarm will sound and the UPS will emit one long beep every 2‐4 seconds. To correct this, turn the UPS off and unplug at least one piece of equipment from the battery‐powered outlets. Wait 10 seconds. Make sure the circuit breaker is depressed and then turn the UPS on. 6. Your UPS is equipped with an auto‐charge feature. When the UPS is plugged into an AC wall outlet ...
-
Page 9: Quickstart Software Installation Guide
XVT‐600, XVT‐800, XVT‐1200, XVT‐1500 USER’S MANUAL UNINTERRUPTIBLE POWER SUPPLY (UPS) QUICKSTART SOFTWARE INSTALLATION GUIDE 1. Locate the USB Cable inside the box. 2. Insert one end of the USB Cable into the UPS and the other into a USB port on your computer. 3. Insert the CD into your computers CD drive. 4. When the software interface requests a serial number, locate and input the serial number from the CD software jacket. 5. Follow the software setup prompts. 6. Quickstart Software Installation Guide. [9] ... - Page 10 XVT‐600, XVT‐800, XVT‐1200, XVT‐1500 USER’S MANUAL UNINTERRUPTIBLE POWER SUPPLY (UPS) Input user name, company name and serial number into the software interface. Note: the serial number is on the CD software jacket. Choose installation location and click “Next” [10] ...
- Page 11 XVT‐600, XVT‐800, XVT‐1200, XVT‐1500 USER’S MANUAL UNINTERRUPTIBLE POWER SUPPLY (UPS) Choose software language and click “Next” Software will install automatically [11] ...
- Page 12 XVT‐600, XVT‐800, XVT‐1200, XVT‐1500 USER’S MANUAL UNINTERRUPTIBLE POWER SUPPLY (UPS) Choose “Will you run Powermanager II right now?” and click “Finish” After the UPS switches on, please choose the “System Setting” tab from the drop down box [12] ...
- Page 13 XVT‐600, XVT‐800, XVT‐1200, XVT‐1500 USER’S MANUAL UNINTERRUPTIBLE POWER SUPPLY (UPS) Click “Local UPS” and choose “USB” click “OK” The UPS is now connected and in normal operation. [13] ...
-
Page 14: Replacing The Battery
XVT‐600, XVT‐800, XVT‐1200, XVT‐1500 USER’S MANUAL UNINTERRUPTIBLE POWER SUPPLY (UPS) REPLACING THE BATTERY (QUALIFIED SERVICE PERSONNEL ONLY) CAUTION! Read and follow the IMPORTANT SAFETY INSTRUCTIONS before servicing the battery. Service the battery under the supervision of Qualified Service Personnel knowledgeable of batteries and their precautions. CAUTION! Use only the specified type of battery. See your dealer for replacement batteries. CAUTION! The battery may present risk of electrical shock. Do not dispose of batteries in a fire as it may explode. Follow all local ordinances regarding proper disposal of batteries. CAUTION! Do not open or mutilate the batteries. Released electrolyte is harmful to skin and eyes and may be toxic. CAUTION! Although the battery system voltage is only 12VDC and 24VDC, the battery can present a high risk of short circuit current and electrical shock. The short circuit current capability of the battery is sufficient to burn wire or tools very rapidly, producing molten metal. Observe these precautions when replacing the battery: 1. Remove all watches, rings or other metal objects. 2. Only use tools with insulated handles. 3. Do not lay tools or metal parts on top of battery or any terminals. 4. Wear protective eye wear (goggles), rubber gloves and boots. 5. Disconnect the charging source before connecting or disconnecting the battery terminals. 6. -
Page 15: Definitions For Led Indicators
XVT‐600, XVT‐800, XVT‐1200, XVT‐1500 USER’S MANUAL UNINTERRUPTIBLE POWER SUPPLY (UPS) DEFINITIONS FOR LED INDICATORS LED 1 LED 2 LED 3 Unit Status (green) (yellow) (red) ON * OFF On AC Power OFF OFF FLASH On Battery * ON * Charge Overheat Low Battery * * ON Overload Protection Short Circuit Note: * means any situation ALARMS Alarm Indication Unit Status Buzzer every 5 sec DC start Buzzer every 1 sec Self test 2 buzzer every 1 sec Low battery ... -
Page 16: Troubleshooting
XVT‐600, XVT‐800, XVT‐1200, XVT‐1500 USER’S MANUAL UNINTERRUPTIBLE POWER SUPPLY (UPS) TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Turn the UPS off & unplug at Full‐time surge protection least one piece of equipment. Circuit breaker has tripped due outlets stop providing power Wait 10 sec, replace the fuse to an overload to equipment with a fuse of like size & rating, & turn the UPS on Recharge the battery for at Battery not fully charged least 4 hours The UPS does not supply Contact Xtreme Power expected runtime The battery is defective Conversion about replacement of batteries The on/off switch is designed Turn the UPS off. Wait 10 sec to prevent damage by rapidly & then turn the UPS on turning it off and on The UPS is not plugged into an Connect the UPS to an AC wall outlet 110/120V 60Hz AC wall outlet The UPS will not turn on Contact Xtreme Power The battery is defective Conversion about replacement of batteries Contact Xtreme Power Mechanical problem ... -
Page 17: Specifications
XVT‐600, XVT‐800, XVT‐1200, XVT‐1500 USER’S MANUAL UNINTERRUPTIBLE POWER SUPPLY (UPS) SPECIFICATIONS 120V Model XVT-600 XVT-800 XVT-1200 XVT-1500 INPUT Voltage 94V-144V ± 5V Capacity VA (W) 600 VA (360 W) 800 VA (480 W) 1200 VA (720 W) 1440 VA (900 W) Frequency 60HZ ± 5Hz OUTPUT Voltage 105-134 VAC (120V ±... -
Page 18: Shipping List
XVT‐600, XVT‐800, XVT‐1200, XVT‐1500 USER’S MANUAL UNINTERRUPTIBLE POWER SUPPLY (UPS) 120V Model XVT-600 XVT-800 XVT-1200 XVT-1500 INDICATORS & AC Mode Green LED on, Orange LED on, Red LED off, no beep ALARMS Charging Battery Orange LED on Battery Mode Green LED and Orange LED off, Red LED flash, buzzer slow beep Battery Low Green LED and Orange LED off, Red LED on, buzzer fast beep ... -
Page 19: Obtaining Service
XVT‐600, XVT‐800, XVT‐1200, XVT‐1500 USER’S MANUAL UNINTERRUPTIBLE POWER SUPPLY (UPS) OBTAINING SERVICE If the UPS requires Service: 1. Use the TROUBLESHOOTING section in this manual to eliminate obvious causes. 2. Verify there are no circuit breakers tripped. 3. Call your dealer for assistance. If you cannot reach your dealer, or if they cannot resolve the problem, call Xtreme Power Conversion Corp Technical Support at 800.582.4524. Technical support inquires can also be made at support@xpcc.com. Please have the following information available BEFORE calling the Technical Support Department: a. Your name and address. b. -
Page 20: Xtreme Power Conversion™ (Xpc) Corporation Limited Warranty
XVT‐600, XVT‐800, XVT‐1200, XVT‐1500 USER’S MANUAL UNINTERRUPTIBLE POWER SUPPLY (UPS) XTREME POWER CONVERSION™ (XPC) CORPORATION LIMITED WARRANTY Xtreme Power Conversion (XPC) Corporation warrants Xtreme Power Conversion equipment, when properly applied and operated within specified conditions, against faulty materials or workmanship (excluding batteries) for a period of two years for XVT‐Series products from the date of purchase. XPC Corporation warrants internal batteries for a period of one year from the date of purchase. For equipment sites within the United States and Canada, this warranty covers repair or replacement, at the ... - Page 21 XVT‐600, XVT‐800, XVT‐1200, XVT‐1500 USER’S MANUAL UNINTERRUPTIBLE POWER SUPPLY (UPS) [21] ...
