- Page 1 A60 Standby UPS 550VA, 750VA Models User & Installation Manual www.xpcc.com | © 2020 Xtreme Power Conversion Corporation. All rights reserved. (Rev 8/24/20)
-
Page 2: Table Of Contents
A60 User’s Manual Uninterruptible Power Supply Table of Contents Installation and Operation................3 LCD Display....................3 Product Overview..................3 LED Indicators....................4 Safety Precautions..................5 Troubleshooting...................6 Specifications....................7 Obtaining Service..................8 Xtreme Power Conversion Limited Warranty..........9 Xtreme Power Conversion Corporation Page 2... -
Page 3: Installation And Operation
1. LCD display or LED indicators (Please check LED or LCD section for the details) 2. Power switch 3. AC input 4. Battery backup outlets 5. Surge-protected outlets 6. USB port (option) 7. Modem/phone/network surge protection (option) 8. Coax surge protection (option) 9. USB charger port (option) Xtreme Power Conversion Corporation Page 3... -
Page 4: Led Indicators
Load level flash. Battery capacity Overload in battery mode When overload occurs, alarm will beep every 0.5 second. icon will flash. NOTE: If backlight shuts off, you may activate it by touching the screen. Xtreme Power Conversion Corporation Page 4... -
Page 5: Safety Precautions
Do not attach non-computer-related items, such as medical equipment, life-support equipment, microwave ovens, or vacuum cleaners to UPS. • A battery can present a risk of electrical shock and high short circuit current. The following precautions should be observed when working on batteries: Xtreme Power Conversion Corporation Page 5... -
Page 6: Troubleshooting
The UPS is overloaded output of the UPS Backup time too short Battery voltage is too low Charge the UPS at least 8 hours Replace the battery with the same Battery defect type of battery Xtreme Power Conversion Corporation Page 6... -
Page 7: Specifications
Data Line Protection RJ-11 and RJ45 (10/100) APPROVALS UL, cUL, RoHS, TAA WARRANTY 3 years electronics, 3 years battery (USA and Canada) COMMUNICATIONS INTERFACE USB and Cable INCLUDED IN BOX USB Cable and User Manual Xtreme Power Conversion Corporation Page 7... -
Page 8: Obtaining Service
RMA number marked on the outside of the boxes. 4. Return the UPS by insured, prepaid carrier to the address provided by the Technician. 5. Refer to the Warranty statements in this manual for additional details on what is covered. Xtreme Power Conversion Corporation Page 8... -
Page 9: Xtreme Power Conversion Limited Warranty
Purchaser’s sole and exclusive remedy for breach of any warranty, expressed or implied, concerning Xtreme Power Conversion equipment, and the only obligation of XPC Corporation under this warranty, shall be the repair or replacement of defective equipment, components, or parts;...
