- Page 1 Network Xtreme Rack/Tower Series NXRT 1000 VA - 3000 VA UPS ■User’s and Installation Manual■...
- Page 2 EMC Statements FCC Part 15 NOTICE: Pursuant to section 15 of the FCC rules, this product has been tested and thereby complies to the conditions of a Class B digital device, which have been established for offering sufficient protection against dangerous interference for installation in a residential area.
-
Page 3: Table Of Contents
CONTENTS 1. Introduction ...................1 2. System description................1 2.1 General description ..................1 2.2 System Configuration...................3 3. Safety Information ................4 4. Storage....................5 5. Installation .....................5 5.1 Environment....................5 5.2 Rear panel views..................8 5.3 Connection to mains and loads ..............11 6. Computer and Alarm connections ............12 6.1 RS-232 Standard Interface port………………………………………………..11 6.2 Net communication SNMP card(option)……………………………………...11 6.3 REPO port (emergency power off)……………………………………………12... - Page 4 IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTION ● CAUTION (UPS Having Internal Batteries): Risk of electric shock - Hazardous live parts inside this unit are energized from the battery supply even when the input AC power is disconnected. ● CAUTION (No User serviceable Parts): Risk of electric shock, do not remove cover.
- Page 5 The instructions contained within this safety manual are deemed important and should be closely followed at all times during installation and follow-up maintenance of the UPS and batteries. CAUTION The unit has a dangerous amount of voltage. If the UPS indicator is on, the unit’s outlets may have a dangerous amount of voltage even when not plugged into the wall outlet because the battery may continue to supply power.
-
Page 6: Introduction
1. Introduction The information provided in this manual covers single phase 1000 – 3000 VA, uninterruptible power systems, their basic functions, operating procedures, and emergency situations, also including information on how to ship, store, handle and install the equipment. Only detailed requirements of the UPS units are described herein, and installation must be carried out in accordance with this manual. - Page 7 Fig.1. Block diagram Diagnostic tests When you start the UPS, a diagnostic test is automatically executed that checks electronics, battery, and reports any problems on the LCD display. An advanced battery management system always monitors the conditions of the batteries sends any forewarnings if replacement is needed.
-
Page 8: System Configuration
2.2 System Configuration The UPS device and the internal backup battery make up the system. Depending on the site and load requirements of the installation, certain additional options are available as a tailored solution. Planning a UPS system, the following should be taken into consideration: * The total demand of the protected system shall dictate the output power rating (VA). -
Page 9: Safety Information
3. Safety Information Information presented here is vital to all personnel and please also read the UPS safety manual. Storage and Transportation Please handle with extreme caution since a high amount of energy is contained with the batteries. Always keep the unit in position as marked on the packaging and never drop the unit. -
Page 10: Storage
4. Storage Please adhere to the following instructions if the UPS is not installed immediately: * Store the equipment as is in its original packing and shipping carton * Do not store in temperatures outside the range of +15°C to +25°C. * Ensure that the equipment is fully protected from wet or damp areas and from moist air. - Page 11 Installations with Multi-Use Brackets: 19” Rack-mount Installation 1K/1.5K UPS & Batter pack Note: Fix a M4*6 screw on four places marked with letter A. 2K/3K UPS & Batter pack Note: Fix a M4*6screw on four places marked with letter A.
- Page 12 23” Rack-mount Installation Installations with Multi-Use Brackets: Tower Installation...
- Page 13 Wall-Mount Installtion Installations with Multi-Use Brackets 4-Bracket 19” Rackmount Installtion...
-
Page 14: Rear Panel Views
Note: Fix a M5*10 screw on eight places marked with letter B. Appearance dimension of M5*10 screw. 5.2 Rear Panel Views Fig. 2 1KVA REAR PANEL (Rack-mount) Fig. 3 1.5KVA REAR PANEL (Rack-mount) - Page 15 Fig. 4 2KVA REAR PANEL (Rack-mount) Fig. 5 3KVA REAR PANEL (Rack-mount)
-
Page 16: Connection To Mains And Loads
5.3 Connection to mains and loads * Ensure that the UPS is disconnected from mains and loads while connecting the External Battery Cabinets, if needed. * Use the battery cable that comes with the External Battery Cabinet to connect the External Battery Cabinet to the UPS. -
Page 17: Computer And Alarm Connections
6. Computer and Alarm connections At the back of the UPS is an interface allowing direct communications with your computer system, the location of which can be found in figure 2. There is a RS232 serial data interface, one and an emergency power off switch supplied. The SNMP/WEB card allows anagement and monitoring over a network or internet. - Page 18 Notes: ● UPS can be monitored through RS232 or SNMP card alternatively, but only one way is allowed at one time. ● User can choose RS232 or SNMP communication through the communication switch on rear panel of UPS.RS232 is chosen if the switch is depressed to the RS232 position, while SNMP is chosen by depressing to the SNMP position.
-
Page 19: User's Guide To Operations
7. User’s guide to operations Necessary information for operation of the unit is covered in this chapter. Normally the UPS runs automatically, but on those few occasions such as just after installation, all the starting and shutting down procedures are described herein. - Page 20 LCD Description and Information There are four lines of information in the LCD display. Each line provides specific information related to the unit status and/or operation. Line information will be described from top to bottom with the top being line one. Line information is as follows: •...
-
Page 21: Starting And Shutting Down The Ups
7.1 Starting and shutting down the UPS On/Off Button Function Button Inquiry Button Starting the UPS from an AC Source * Ensure that installation was correct and successful and that the input power cable is connected to a well-grounded outlet. * Please note: :Once the UPS has been connected to an AC power source the internal charger will start charging the batteries, at this point the yellow LED is illuminated and the LCD displays “On BPS”. -
Page 22: Self Test Operation
Turning Off the UPS when in DC Mode * Press and hold the START/OFF button for more than 3 seconds to turn off the UPS. This means the internal inverter has been deactivated. * During the shutdown period the UPS will run a self test. Once self test has been completed, assuming there is still no AC input, the LCD will no longer display information. -
Page 23: Interpreting Ups Messages
7.3 Interpreting UPS messages Troubleshooting procedures described here give simple instructions in determining UPS malfunctions. Start the troubleshooting procedure if you witness any alarm indication on the control panel. Alarm indicators The UPS gives the following audible alarms: * If UPS is on battery and the ON BATTERY LED is on, UPS will beep every 5 seconds. * If the battery capacity is low and the ON BATTERY LED is flashing, the UPS will beep twice every 5 seconds. -
Page 24: Trouble Shooting
7.5 Trouble shooting The following messages are the messages that users would find on UPS when it encounters a problem, with the use of such messages, users can quickly identify problems are and how to deal with such problems. ● Fault indicator on, indicates UPS has detected some fault. ●... - Page 25 Trouble Shooting Table Issue Audible Alarm Alarm Description What You Should Do Verify that utility voltage and Two Beeps per The “Input” letters in The Input Voltage or frequency is within acceptable second at startup the second row of the frequency may be beyond range.
-
Page 26: Maintenance
8．Maintenance The most critical issues impacting the performance and reliability of the UPS are environmental issues. Ensure that the temperature and humidity are always within specifications and keep the area around the unit clean and dust free. At a temperature of 25°C, the typical battery lifetime is approximately 4 years. Also, check at regular intervals of 6 to 12 months whether the back-up time of the battery is adequate. - Page 27 1. Slide plastic front cover to the right Note: Remove the M5*10 screw on the right side. 2. Remove plastic front cover...
- Page 28 3. Locate the battery “cartridge” on the right front side of the UPS 4. Remove the four screws from the front of the battery cartridge Note: Remove four M4*6 screws marked with letter A on the disassembly figure. 5．Remove the battery cartridge from the UPS...
-
Page 29: Technical Specifications
9. Technical Specifications ◆Electrical performance MODEL NXRT-1000 NXRT-1500 NXRT-2000 NXRT-3000 Rated load 1KVA/700W 1.5KVA/1050W 2KVA/1400W 3KVA/2100W Rated voltage 110/115/120Vac Rated frequency 50/60Hz ◆ AC input MODEL NXRT-1000 NXRT-1500 NXRT-2000 NXRT-3000 When load≤60% Input voltage range is 55±V~138±5V Voltage When 60%<load≤70% Range Input voltage range is 60±5V~138±5V When... - Page 30 Internal battery 3PCS 4PCS 8PCS 8PCS Capacity 9AH/12V 7.2AH/12V 7.2AH/12V 7.2AH/12V Backup time >12 min >12min >20min >16min (half load) Backup time >5min >5min >7min >5min (full load) Recharge time <8hours to 90% ◆ Output MODEL NXRT-1000 NXRT-1500 NXRT-2000 NXRT-3000 Voltage tolerance 110/115/120Vac(1±2%) Frequency tolerance...
-
Page 31: Obtaining Service/Warranty
Store temperature -25℃~55℃ ◆ Mechanical Specification MODEL NXRT-1000 NXRT-1500 NXRT-2000 NXRT-3000 Dimension 440*450*86.5 440*650*86.5 440*550*131 440*550*131 W*D*H(mm) Weight Net Weight Kilogram Gross Weight 10. Obtaining Service/Warranty If the UPS requires Service: 1. Use the TROUBLESHOOTING section to eliminate obvious causes. 2. -
Page 32: Limited Warranty
5. Mark the RMA # on the outside of all packages. The factory cannot accept any package without the RMA # marked on the outside. 6. Return the UPS by insured, prepaid carrier to: Xtreme Power Conversion for ____Call: address... - Page 33 11. Limited Three Year Warranty NXRT Series UPS products are warranted free from defects in material and workmanship for three years from date of purchase. This warranty is limited to repairing or replacing, at Xtreme Power’s sole option, any defective component, circuit board or module contained within the product, only when it is returned with an Xtreme Power Return Material Authorization (RMA) number to Xtreme Power.
- Page 34 Logistics and Shipping Unless otherwise stated, the warranty period begins on the date the Xtreme Power product is shipped to the customer when shipped from an Xtreme Power owned facility. In cases in which products are purchased through and shipped from a Distributor or a Reseller, the warranty period begins 60 days from the date of shipment from Xtreme Power.
