11. Tables

ATTENTION
The correct type of cable and it´s size is depending on current and type of installation. The input current together
with the rated power are given in chapter 2. The coresponding battery current is given in Tab. 6. This are recom-
mendations; local regulation are valid only.
ATTENTION
The following Tab. give only hints to needed cable size. Type of installation: Single cable with standard isolation
PVC, no multicable installation.
Tab. 1
UPS TRI POWER X33 MOD HP recommendet cable size
no. of phases
Rated power
input
3
1
10kVA
1
3
3
1
15/20kVA
1
3
30kVA 3
40kVA 3
45kVA 3
60kVA 3
Tab. 2
Fuses UPS TRI POWER X33 MOD HP
Rated power
10/15/20 kVA N.1 - 50A 500V aR (22 x 58)
Tab. 3
Fuses UPS TRI POWER X33 MOD HP® BATTERY/2
Rated power
10/15/20/30/40/45/60 kVA
Tri Power X33 Mod HP Manual | Rev 1.20 | © Alpha Technologies GmbH 2013
Tri Power X33 Mod HP
no. of phases cable size
output input
3 5 x (4mm²)
1 3 x (10mm²)
3 3 x (10mm²)
1 5 x (10mm²)
3 5 x (10mm²)
1 3 x (25mm²)
3 3 x (25mm²)
1 5 x (25mm²)
3 5 x (16mm²)
3 5 x (25mm²)
3 5 x (25mm²)
3 5 x (35mm²)
zylinder fuse
USV TRI POWER X33 MOD HP® internal battery system
FB+
zylinder fuse
USV TRI POWER X33 MOD HP® BATTERY modulear 5KB
FB+
N.5- 50A 500V aR (14 x 51)
cable size
output
5 x (4mm²)
3 x (10mm²)
5 x (4mm²)
3 x (10mm²)
5 x (25mm²)
3 x (10mm²)
5 x (25mm²)
3 x (95mm²)
5 x (16mm²)
5 x (25mm²)
5 x (25mm²)
5 x (35mm²)
FB-
N.1 - 50A 500V aR (22 x 58)
FB-
N.5 - 50A 500V aR (14 x 51)
