5. Installation
5.3.4 3-PHASE-Input, 1-PHASE-Output connection
For this type of connection, besides the wiring shown in the following figure, the software has to be configured via the
instrument panel as illustrated in paragraph 6.4 STARTING PROCEDURE.
WARNING
If the links are set for single phase output please take attention to chapter 5.3.3. If the setting are not done before
the first commissioning the UPS can be completly damaged.
Tri Power X33 Mod HP Manual | Rev 1.20 | © Alpha Technologies GmbH 2013
Tri Power X33 Mod HP
TRI POWER X33 MOD HP
10/15/20
41
