7. Bedienfeld
PM Status
Note: To choose the Phase X press the ENTER key.
Diagnostics (*)
PM SW Update (*)
(*) Only available in „SERVICE-MODE".
Tri Power X33 Mod HP Manual | Rev 1.20 | © Alpha Technologies GmbH 2013
62
Battery X
PM
Measure-
ments
Misc. X
Run Time
Battery time
BattCharg time
Bypass int.
Battery int.
PM histori-
Dumper int.
cal data
No. Overheat
No. Overloads
No. HV Bus run
No. Out DC Level
Reset PM Errors Deletes the memory of errors found in the power module.
It allows the sequential and automatic updating of the internal soft-
ware of all the UPS power modules. Press 'ENTER' to start the proce-
Update all the PWs dure. If the update is unnecessary the following message appears on
the display:
'PM SW versions updated!' Press 'ESC' to exit the frame.
It allows the updating of the internal software of a single power mo-
dule. Using the 'ARROW' keys you select the module you wish to
update ('PM00' indicates the module at the top on the left, going on
to the last one at the bottom on the right). By pressing 'ENTER' key a
Update a single PW frame appears that gives a comparison between the software that is
actually in the module selected and the software you are about to
load. Press 'ENTER' to start the update procedure.
Once updated, the message 'PM SW version updated!' appears on
the display. Press 'ESC' to exit the frame.
Voltage measured at the ends of the
Voltage
batteries by the power module X [V]
Current required to the batteries from
Current the power module X (negative if the
batteries are being charged) [A]
Status of the battery charger inside
Batt. Cahrger
module X
INV. dissip. Temperature of the INV dissipater
Temp. (Inverter) of the power module X [°C]
Temperature of the BST (Booster) dissi-
BST dissip. Temp.
pater of the power module X [°C]
Fan speed expressed as a percentage of
Fan speed
the power module X
Voltage on the DC BUS positive of the
Pos.H.V.Bus
power module X [V]
Voltage on the DC BUS negative of the
Neg.H.V.Bus
power module Xm [V]
Total time working
Total time running on battery
Total time the battery charger has been working
Total number of bypass interventions
Total number of battery interventions
Total number of dumper interventions
Total number of overheatings
Total number of overloads
Total number of overvoltages on the Bus
Total number of continuous voltage presences in output
from the PMs
