8.2 Messages

In this paragraph the messages that appear on the unit's display are listed, also giving the most likely cause that could
have generated them. If you are unable to solve the problem then please contact the Technical Service.
FIRST LINE OF THE MAIN FRAME
Message
SERVICE MODE
UPS START-UP
UPS IN BYPASS
FORCED BYPASS
BYPASS INPUT KO
OUTPUT OFF
UPS ON BATTERY
BATTERY CALIBRATION
BATTERY TEST
BATTERY EQUALIS.
BUZZER OFF
AUTONOMY RESERVE!
MODULE FAILED
BATTERIES KO
OVERLOAD
OVERHEATING
DC OUT LEVEL FAILURE
HVBUS RUNAWAY FAILURE
RUNAWAY BATTERIES
3V BATTERY FLAT
SHUTDOWN IN PROGRESS
BATTERIES BEING CHARGED
UPS IN EMERGENCY!
UPS OFF!
UPS STOPPED!
NO MAINS
VERY HIGH MAINS
MAINS OFF TOLL
MAINS NOT SYNC.
INCORRECT SEQUENCE
Tri Power X33 Mod HP Manual | Rev 1.20 | © Alpha Technologies GmbH 2013
Tri Power X33 Mod HP
Meaning
UPS in the Service Mode. All settings via the display, maintenance functi-
ons and updates are possible
UPS starting up. The UPS control system checks the correct configuration
status before entering the 'Normal' or 'Service' operating mode.
The UPS is in Bypass during this initialisation phase.
UPS in Bypass. The load is not protected by the UPS in this configuration.
The UPS has entered the forced Bypass mode via configuration on the
display
Bypass input KO; some problems have arisen on the Bypass line.
It is not possible to feed the loads directly off the mains.
Output off. Configuration obtained via the display or subsequent to a
UPS malfunction
UPS on battery. The cause for this configuration is a failure in the UPS
feeding system.
The UPS is calibrating the batteries.
The UPS is testing the batteries to check their status and that they are
working properly.
The UPS is equalising the batteries.
The buzzer is turned off.
Battery charge level is at minimum.
One or more Power Modules have failed. They must either be repaired
or changed.
Batteries failed. Check their operation and replace them if necessary.
The total load is higher than the UPS's rated power.
Switching to Bypass.
The temperature inside the UPS is outside the nominal range.
A failure of the UPS has caused a DC voltage in output.
A failure of the UPS has caused a voltage level on the High Voltage Bus
out of control.
Battery voltage out of control. Either the batteries or battery charger
are/is malfunctioning.
The control board's 3V battery is flat.
The UPS is shutting down.
The UPS is charging the batteries.
UPS in emergency.
UPS off.
The UPS has stopped.
No mains.
The mains voltage is very high but still inside the range allowed.
Mains voltage is out of the range allowed. The UPS switches to battery
and bypass is disabled.
Mains not synchronised; bypass disabled.
Invalid input sequence, check correct supply connection.
to be continued next page
