7.2.1 Status UPS

Modell TRI POWER X33 MOD HP
Synchronisation adress
Info USV
X/X - X/X -X/X
USV Setup
Batt.Cap.
No. each string
Output
Measurements
X
Note: To change the phase X press the ENTER key.
Tri Power X33 Mod HP Manual | Rev 1.20 | © Alpha Technologies GmbH 2013
Synchronisation adress of the command
CM-Number Number of the given command
VA max Maximum supplaiable apparent power [kVA]
W max Maximum supplaiable active power [kW]
IBat max Maximum charge current [A]
SW Vers. Firmware-Version of UPS
PM SW Vers. Firmware-Version of Power module
SW Ver.Boot Version of Bootloaders of UPS
S/N Serial number of UPS
Inverter Configuration: 1-phase / 3-phase 120° / 3 single phases
Input Configuration: 1-phase / 3-phase / 3-phase reverse / not defined
X (count) Power module each phase
No. BCM no. of installed Power chargers
No. KB No. of installed battery strings (4 Battery module = 1 string KB)
Battery capacity each battery module
total no. of battery blocks 12V each string
Power Active power supplied by UPS on phase X [W]
App.Pow. Apparent Power supplied by the UPS on phase X [W]
Vrms Effective voltage supplied by UPS on phase X [V Rms]
Vrms ph-ph Effective line voltage supplied by UPS on phase X [V Rms]
Irms Effective current supplied by UPS on phase X [A Rms]
Peak I Val. Peak current supplied in output from the UPS on phase X [A]
Frequency Frequency of the sinusoid voltage in output from phase X [Hz]
Crest Factor Crest factor of the load connected on phase X
Power factor Power factor of the load connected to the UPS on phase X
W Max Maximum available active power on phase X [W]
Wirklstg. actual active power on phase X [W]
VA Max Maximum available apparent power on phase X [VA]
Scheinlstg. actual appartent power on phase X [VA]
Tri Power X33 Mod HP
Equipment model
