Alpha Technologies Tri Power X33 Mod HP series Operating And Maintenance Manual page 16

Technical specification battery charger module
INPUT
Input voltage range
max. Input current
Power factor
THD input current
OUTPUT
Float charge voltage
max. charging current
Efficency AC/DC
DESCRIPTION
Multicolor LED indicator on
front or information through
UPS display
ENVIROMANTAL CONDITIONS
Operation temperature
Relative humidity
Noise level at 1m
Grade of protection
STANDARDS FULLFILLED
EN62040-1, EN62040-2, EN62040-3
Tri Power X33 Mod HP Manual | Rev 1.20 | © Alpha Technologies GmbH 2013
16
13,75Vdc / battery block 12V
> 93% at maximum charging current
yellow LED fast flashing: Boost charge phase f1 with constant current
green LED slow flashing: Charging phase f2 with constant voltage or float charge
green LED on: Battery system in standby (no charging)
red LED on: Fault
20% - 80% non-condensing
230Vac +15% - 20%
19,3 A
> 0.99
THDi < 3%
15 Adc
0° - 40° C
42 - 46 dBA
IP 20 (IEC 529)
