Mirror Port Commands

This section describes how to mirror traffic from a source port to a target port.
Command

port monitor

show port monitor
port monitor
This command configures a mirror session. Use the no form to clear a mirror
session.
Syntax
port monitor interface [rx | tx]
no port monitor interface
• interface - ethernet unit/port (source port)
- unit - Stack unit. (Always unit 1)
- port - Port number. (Range: 1-26/50)
• rx - Mirror received packets.
• tx - Mirror transmitted packets.
Default Setting
No mirror session is defined.
Command Mode
Interface Configuration (Ethernet, destination port)
Command Usage
• You can mirror traffic from any source port to a destination port for real-time
analysis. You can then attach a logic analyzer or RMON probe to the
destination port and study the traffic crossing the source port in a completely
unobtrusive manner.
• The destination port is set by specifying an Ethernet interface.
• The mirror port and monitor port speeds should match, otherwise traffic may
be dropped from the monitor port.
• All mirror sessions must share the same destination port.
• When mirroring port traffic, the target port must be included in the same VLAN
as the source port
Table 4-44 Mirror Port Commands
Function
Configures a mirror session
Shows the configuration for a mirror port
Mirror Port Commands
Mode
IC
PE
4
Page
4-127
4-128
4-127
