3
Configuring the Switch
CLI – This example allows SNMP access for a specific client.
Console(config)#management snmp-client 10.1.2.3
Console(config)#end
Console#show management all-client
Management IP Filter
HTTP-Client:
Start IP address
-----------------------------------------------
SNMP-Client:
Start IP address
-----------------------------------------------
1. 10.1.2.3
TELNET-Client:
Start IP address
-----------------------------------------------
Console#

Port Configuration

Displaying Connection Status

You can use the Port Information or Trunk Information pages to display the current
connection status, including link state, speed/duplex mode, flow control, and
auto-negotiation.
Field Attributes (Web)
• Name – Interface label.
• Type – Indicates the port type. (100BASE-TX, 1000BASE-T, or SFP)
• Admin Status – Shows if the interface is enabled or disabled.
• Oper Status – Indicates if the link is Up or Down.
• Speed Duplex Status – Shows the current speed and duplex mode.
(Auto, or fixed choice)
• Flow Control Status – Indicates the type of flow control currently in use.
(IEEE 802.3x, Back-Pressure or None)
• Autonegotiation – Shows if auto-negotiation is enabled or disabled.
3
• Media Type – Media type used for the combo ports 21-24 (SMC8126L2) or 45-48
(SMC8150L2).
(Options: Coppper-Forced, SFP-Forced, or SFP-Preferred-Auto; Default:
SFP-Preferred-Auto)
• Trunk Member
5
• Creation – Shows if a trunk is manually configured or dynamically set via LACP.
3. Port information only.
4. Port information only.
5. Trunk information only.
3-76
End IP address
End IP address
10.1.2.3
End IP address
4
– Shows if port is a trunk member.
4-27
