Figure 3-55 Lacp - Port Internal Information - SMC Networks SMC8126L2 Management Manual

Web – Click Port, LACP, Port Internal Information. Select a port channel to display
the corresponding information.
CLI – The following example displays the LACP configuration settings and
operational state for the local side of port channel 1.
Console#show lacp 1 internal
Port channel : 1
-------------------------------------------------------------------------
Oper Key : 120
Admin Key : 0
Eth 1/1
-------------------------------------------------------------------------
LACPDUs Internal:
LACP System Priority: 3
LACP Port Priority:
Admin Key:
Oper Key:
Admin State : defaulted, aggregation, long timeout, LACP-activity
Oper State:
.
.
.

Figure 3-55 LACP - Port Internal Information

30 sec
128
120
120
distributing, collecting, synchronization,
aggregation, long timeout, LACP-activity
3
Port Configuration
4-136
3-89
