4
Command Line Interface
Command Mode
Privileged Exec
Example
This shows that traffic entering Port 1 that matches the specifications for protocol
group 1 will be mapped to VLAN 2:
Console#show interfaces protocol-vlan protocol-group
Port ProtocolGroup ID
---------- ------------------ -----------
Eth 1/1
Console#

Priority Commands

The commands described in this section allow you to specify which data packets
have greater precedence when traffic is buffered in the switch due to congestion.
This switch supports CoS with four priority queues for each port. Data packets in a
port's high-priority queue will be transmitted before those in the lower-priority
queues. You can set the default priority for each interface, the relative weight of each
queue, and the mapping of frame priority tags to the switch's priority queues.
Command Groups
Priority (Layer 2)
Priority (Layer 3 and 4)

Priority Commands (Layer 2)

Command
queue mode
switchport priority default
queue bandwidth
queue cos map
show queue mode
show queue bandwidth
show queue cos-map
show interfaces switchport Displays the administrative and operational status of an
4-184
Vlan ID
1 vlan2
Table 4-61 Priority Commands
Function
Configures default priority for untagged frames, sets queue weights,
and maps class of service tags to hardware queues
Maps IP DSCP tags to class of service values
Table 4-62 Priority Commands (Layer 2)
Function
Sets the queue mode to strict priority or Weighted
Round-Robin (WRR)
Sets a port priority for incoming untagged frames
Assigns round-robin weights to the priority queues
Assigns class-of-service values to the priority queues
Shows the current queue mode
Shows round-robin weights assigned to the priority queues
Shows the class-of-service map
interface
Page
4-184
4-189
Mode Page
GC 4-185
IC 4-185
GC 4-186
IC 4-187
PE 4-188
PE 4-188
PE 4-189
PE 4-125
