Configuring the Switch
• Port Security – Shows if port security is enabled or disabled.
• Max MAC count – Shows the maximum number of MAC address that can be
learned by a port. (0 - 1024 addresses)
• Port security action – Shows the response to take when a security violation is
detected. (shutdown, trap, trap-and-shutdown, or none)
Current Status:
• Link Status – Indicates if the link is up or down.
• Port Operation Status – Provides detailed information on port state.
(Displayed only when the link is up.)
• Operation speed-duplex – Shows the current speed and duplex mode.
• Flow control type – Indicates the type of flow control currently in use.
(IEEE 802.3x, Back-Pressure or none)
CLI – This example shows the connection status for Port 5.
Console#show interfaces status ethernet 1/5
Information of Eth 1/5
Basic information:
Port type:
Mac address:
Configuration:
Name:
Port admin:
Speed-duplex:
Capabilities:
Broadcast storm:
Broadcast storm limit:
Flow control:
Lacp:
Port security:
Max MAC count:
Port security action:
Current status:
Link status:
Operation speed-duplex: 100full
Flow control type:
Console#

Configuring Interface Connections

You can use the Port Configuration or Trunk Configuration page to enable/disable an
interface, set auto-negotiation and the interface capabilities to advertise, or manually
fix the speed, duplex mode, and flow control.
Command Attributes
• Name – Allows you to label an interface. (Range: 1-64 characters)
• Admin – Allows you to manually disable an interface. You can disable an interface
due to abnormal behavior (e.g., excessive collisions), and then reenable it after the
problem has been resolved. You may also disable an interface for security
reasons.
3-78
100TX
00-12-CF-12-34-61
Up
Auto
10half, 10full, 100half, 100full
Enabled
500 packets/second
Disabled
Disabled
Disabled
0
None
Down
None
