Enabling Igmp Filtering And Throttling; Figure 3-103 Enabling Igmp Filtering And Throttling - SMC Networks SMC8126L2 Management Manual

3
Configuring the Switch
switch randomly removes an existing group and replaces it with the new multicast
group.
Note:
IGMP filtering and throttling only applies to dynamically learned multicast groups, it
does not apply to statically configured groups.

Enabling IGMP Filtering and Throttling

To implement IGMP filtering and throttling on the switch, you must first enable the
feature globally and create IGMP profile numbers.
Command Attributes
• IGMP Filter – Enables IGMP filtering and throttling globally for the switch.
(Default: Disabled)
• IGMP Profile – Creates IGMP profile numbers. (Range: 1-4294967295)
Web – Click IGMP Snooping, IGMP Filter Configuration. Create a profile number by
entering the number in text box and clicking Add. Enable the IGMP filter status, then
click Apply.
CLI – This example enables IGMP filtering and creates a profile number, then
displays the current status and the existing profile numbers.
Console(config)#ip igmp filter
Console(config)#ip igmp profile 19
Console(config-igmp-profile)#end
Console#show ip igmp filter
IGMP filter enable
Console#show ip igmp profile
IGMP Profile 19
IGMP Profile 50
Console#
3-170

Figure 3-103 Enabling IGMP Filtering and Throttling
