Web – Click Cluster, Member Configuration.
CLI – This example creates a new cluster Member by specifying the Candidate
switch MAC address and setting a Member ID.
Console(config)#cluster member mac-address 00-12-34-56-78-9a id 5
Console(config)#

Cluster Member Information

Displays current cluster Member switch information.
Command Attributes
• Member ID – The ID number of the Member switch. (Range: 1-16)
• Role – Indicates the current status of the switch in the cluster.
• IP Address – The internal cluster IP address assigned to the Member switch.
• MAC Address – The MAC address of the Member switch.
• Description – The system description string of the Member switch.
Web – Click Cluster, Member Information.

Figure 3-124 Cluster Member Configuration

Figure 3-125 Cluster Member Information

3
Switch Clustering
4-240
3-197
