Mechanical Installation - THORLABS K-Cube Piezo Controller User Manual

Chapter 3

3.2 Mechanical Installation

The safety of any system incorporating this equipment is the
responsibility of the person performing the installation.
3.2.1 Environmental Conditions
Operation outside the following environmental limits may adversely
Location
Maximum altitude
Temperature range
Maximum Humidity
To ensure reliable operation the unit should not be exposed to corrosive agents or
excessive moisture, heat or dust.
If the unit has been stored at a low temperature or in an environment of high humidity,
it must be allowed to reach ambient conditions before being powered up.
3.2.2 Mounting Options
The K-Cube Piezo Driver is shipped with a baseplate, for use when fitting the unit to
a breadboard, optical table or similar surface.
For multiple cube systems, a 3-channel and 6-channel K-Cube Controller Hub
(KCH301 and KCH601). ) are also available - see Section 2.2. for further details. Full
instructions on the fitting and use of the controller hub are contained in the handbook
available at www.thorlabs.com
When siting the unit, it should be positioned so as not to impede the
Ensure that proper airflow is maintained to the rear of the unit
10
Warning
Warning
affect operator safety.
Indoor use only
2000 m
o o
5 C to 40 C
Less than 80% RH (non-condensing) at 31°C
Cautions
operation of the control panel buttons.
HA0365T Rev Dk Jan 2017
