THORLABS K-Cube Piezo Controller User Manual page 28

Chapter 4
4.4.10 Menu Option - 8 Wheel lock
In certain applications, it may be advantageous to disable the wheel to remove the
possibility of unwanted motion due to accidental movement of the wheel.
V o l t a g e : 3 5 . 3 0 V V o l t a g e : 3 5 . 3 0 V
1 5 0 V A J 1 5 0 V A J
MENU
M e n u o p t i o n s
U s e w h e e l
M e n u o p t i o n s
8 W h e e l l o c k
W h e e l u n l o c k e d
t o c h a n g e
W h e e l l o c k e d
t o c h a n g e
V o l t a g e : 3 5 . 3 0 V
1 5 0 V A J
28
Press the MENU button, then use the wheel to scroll
through the menu options.
Press the MENU button to enter the 8 Wheel lock option.
The display shows the current setting.
Use the wheel to select
unlocked' as required.
Press the MENU button to store the selection and return to
the main display.
'Wheel locked' or 'Wheel
HA0365T Rev Dk Jan 2017
