4.4.2 Menu Option - HV output
This mode is used to enable or disable the drive output.
Press the MENU button, then use the wheel to scroll
through the menu options.
Press the MENU button to enter the 1 HV output option.
The display shows the current setting.
Use the wheel to enable/disable the output.
Press the MENU button to store the selection and return
to the operating screen.
4.4.3 Menu Option - Voltage range
The piezo actuator connected to the cube has a specific
maximum operating voltage range. This mode is used to
set the maximum drive voltage for the actuator connected
to the unit.
Press the MENU button, then use the wheel to scroll
through the menu options.
Press the MENU button to enter the 2 Voltage range
option.
The display shows the current setting.
Use the wheel to set the voltage associated with your
piezo actuator, 75V, 100V or 150V.
Press the MENU button to save the setting and return to
the operating screen.
K-Cube Piezo Driver
O u t p u t i n a c t i v e
7 5 V N V
MENU
M e n u o p t i o n s
U s e w h e e l
M e n u o p t i o n s
1 H V o u t p u t
H V d i s a b l e d
t o c h a n g e
H V e n a b l e d
t o c h a n g e
V o l t a g e : 0 . 0 0 V
7 5 V N V
V o l t a g e : 0 . 0 0 V
7 5 V N V
MENU
M e n u o p t i o n s
U s e w h e e l
M e n u o p t i o n s
2 V o l t a g e r a n g e
R a n g e 7 5 V
t o c h a n g e
R a n g e 1 5 0 V
t o c h a n g e
V o l t a g e : 0 . 0 0 V
1 5 0 V N V
