4.4.9 Menu Option - Teach voltage
This mode is used to set the teach positions, used when the Joystick mode option is
set to Go to voltages mode - see Section 4.4.7.
To set Teach Voltage 1...
Using the method described in Section 4.4.7. and Section
4.4.8. set the drive voltage to the value required as teach
voltage 1, then...
press the MENU button, and use the wheel to scroll
through the menu options.
Press the MENU button to enter the 7 Teach voltage
option.
Use the wheel to select V1, then press the MENU button
to store the present voltage setting as teach voltage 1 and
return to the main display.
When Go to voltages mode is selected in the Joystick
mode option (see Section 4.4.7.), an upwards deflection
of the wheel changes the drive voltage to V1, and an
downwards deflection changes the drive voltage to V2.
To set Teach Voltage 2...
Using the method described in Section 4.4.7. and Section
4.4.8. set the drive voltage to the value required as teach
voltage 2, then...
press the MENU button, and use the wheel to scroll
through the menu options.
Press the MENU button to enter the 7 Teach voltage
option.
Use the wheel to select V2, then press the MENU button
to store the present voltage setting as teach voltage 2 and
return to the main display.
When Go to voltages mode is selected in the Joystick
mode option (see Section 4.4.7.), an upwards deflection
of the wheel changes the drive voltage to V1, and an
downwards deflection changes the drive voltage to V2.
K-Cube Piezo Driver
V o l t a g e : 3 5 . 3 0 V
1 5 0 V A J
MENU
M e n u o p t i o n s
U s e w h e e l
M e n u o p t i o n s
7 T e a c h v o l t a g e
V 1 : 3 5 . 3 0 V
n u m s t o r e
V o l t a g e : 3 5 . 3 0 V
1 5 0 V A J
V o l t a g e : 6 0 . 7 5 V
1 5 0 V A J
MENU
M e n u o p t i o n s
U s e w h e e l
M e n u o p t i o n s
7 T e a c h v o l t a g e
V 2 : 6 0 . 7 5 V
n u m s t o r e
V o l t a g e : 6 0 . 7 5 V
1 5 0 V A J
