moves. The trigger input has to return to its inactive state first in order to start the next
trigger. The mode is set in the Trigger 1 Mode and Trigger 2 Mode parameters as
follows:
Disabled - The trigger IO is disabled
Digital Input - General purpose logic input (read through status bits using the
LLGetStatusBits method).
Trigger Input Jog Up - Input trigger for voltage step up. On receipt of the trigger,
the drive voltage increases by the value set in the Voltage Step parameter.
Trigger Input Jog Down - Input trigger for absolute move. On receipt of the trigger,
the drive voltage decreases by the value set in the Voltage Step parameter.
When the Trig 1 Mode and Trig 2 Mode parameters are configured as outputs, the
TRIG ports can be used as a general purpose digital output as follows:
Digital Output - General purpose logic output (set using the LLSetGetDigOPs
method).
Triggering Polarity
The polarity of the trigger pulse is specified in the Trig. 1 Polarity and Trig 2 Polarity
parameters as follows:
Active High - The active state of the trigger port is logic HIGH 5V (trigger input and
output on a rising edge).
Active Low - The active state of the trigger port is logic LOW 0V (trigger input and
output on a falling edge).
