3.2 Mechanical Installation

3.2.1 Environmental Conditions
This unit is designed for operation within normal operational limits. It is not
recommended to use this equipment outside the following limits.
Location
Maximum altitude
Temperature range
Maximum Humidity
To ensure reliable operation the unit should not be exposed to corrosive agents or
excessive moisture, heat or dust.
If the unit has been stored at a low temperature or in an environment of high humidity,
it must be allowed to reach ambient conditions before being powered up.
3.2.2 Mounting Options
The T-Cube Stepper Driver is shipped with a baseplate fitted, ready to be bolted to a
breadboard, optical table or similar surface.
If desired, the baseplate can be removed and the unit can be stood on rubber feet -
see Section 3.2.3.
For multiple cube systems, a USB controller hub (TCH002) is available - see Section
2.2. for further details. Full instructions on the fitting and use of the controller hub are
contained in the associated handbook, available at www.thorlabs.com.
When siting the unit, it should be positioned so as not to impede the
Ensure that proper airflow is maintained to the rear of the unit.
Caution
Indoor use only
2000 m
o o
5 C to 40 C
Less than 80% RH (non-condensing) at 31°C
Caution
operation of the control panel buttons.
T-Cube Stepper Motor Controller
11
