3.3.3 Front Panel
The unit must be connected only to a DC supply as detailed in Section 3.3.
Connection to a supply of a different rating may cause damage to the unit and
Ensure the power switch on the front panel of the unit is switched off
before connecting power to the K-Cube. Always power up the K-Cube unit
by its ON switch. DO NOT connect the K-Cube unit to a 'live' external
power supply. Doing so (i.e. "hot plugging") carries the risk of
PERMANENT damage to the unit. Similarly, to power down the unit, turn
the power switch off before disconnecting the power supply.
POWER - Eight pin connector for connecting the unit to a regulated DC power supply
of the rating detailed in Section 3.3.
USB - USB port for system communications.
The USB cable length should be no more than 3 metres unless a powered
ON - Power ON/Standby switch - seeSection 3.3.5.
TRIG 1 and TRIG 2 - SMA connectors for use with external trigger input and output
signals (5V TTL levels). The function is set to trigger IN or OUT via the settings panel
- see Section 6.2.3.
Warning
could result in injury to the operator.
Caution
KPZ101
+5V TTL
USB
Fig. 3.3 Front Panel
Note
USB hub is being used.
P
O
+5V TTL
W
E
R
K-Cube Piezo Driver
