Schematic

U_Audio
Audio.SchDoc
Audio_OUT_L
Audio_OUT_R
Audio_IN
U_CAN_SmartCard_IR
CAN_SmartCard_IR.SchDoc
CAN_RX
CAN_TX
IR_OUT
IR_IN
SmartCard_IO
SmartCard_CLK
SmartCard_RST
SmartCard_OFF
SmartCard_3/5V
SmartCard_CMDVCC
SmartCard_1V8
U_HDMI_CEC
HDMI_CEC.SchDoc
HDMI_HPD_Source_5V
I2C1_SCL_5V
I2C1_SDA_5V
HDMI_HPD_SINK
I2C2_SCL_5V
I2C2_SDA_5V
HDMI_CEC_3V3
U_TemSensor_RF_EEPROM
TemSensor_RF_EEPROM.SCHDOC
I2C1_SCL_5V
I2C1_SDA_5V
TempSensor_INT
ACP_RST
U_Peripherals
Peripherals.SchDoc
Potentiometer
LDR_OUT
Tamper_key
JOY_SEL
JOY_UP
JOY_DOWN
JOY_LEFT
JOY_RIGHT
LED1
LED2
LED3
LED4
U_Touch Sensing
Touch Sensing.SchDoc
SHIELD
SHIELD_CT
TS1
TS2
TS_CT
DB_PD12
DB_PD13
DB_PD14
DB_PB11
DB_PB12

Figure 21. STM32091C-EVAL top view

U_MCU
MCU.SchDoc
Audio_OUT_L 8xUSART1_TX
Audio_OUT_R 8xUSART2_TX
Audio_IN 8xUSART3_TX
8xUSART4_TX
8xUSART5_TX
8xUSART6_TX
CAN_RX 8xUSART7_TX
CAN_TX 8xUSART8_TX
IR_OUT
IR_IN 8xUSART1_RX
SmartCard_IO 8xUSART2_RX
SmartCard_CLK 8xUSART3_RX
SmartCard_RST 8xUSART4_RX
SmartCard_OFF 8xUSART5_RX
SmartCard_3/5V 8xUSART6_RX
SmartCard_CMDVCC 8xUSART7_RX
SmartCard_1V8 8xUSART8_RX
HDMI_HPD_Source
I2C1_SCL
I2C1_SDA
HDMI_HPD_SINK_OD
I2C2_SCL
I2C2_SDA
HDMI_CEC_OD
SPI1_SCK
SPI1_MOSI
SPI1_MOSI_DIR
SPI1_MISO
MicroSD_CS_OD
TempSensor_INT LCD_CS_OD
ACP_RST_OD SDcard_detect
RESET#
Potentiometer SWCLK
LDR_OUT SWDAT
Tamper_key
JOY_SEL
JOY_UP
JOY_DOWN
JOY_LEFT
JOY_RIGHT
LED1
LED2 USART5_TX
LED3 USART5_RX
LED4
SHIELD
SHIELD_CT
TS1
TS2 USART1_RX
TS_CT USART1_TX
DB_PD12 USART1_RTS
DB_PD13 USART1_CTS
DB_PD14 Bootloader_BOOT0
DB_PB11 Bootloader_RESET
DB_PB12
U_8x_USART
8x_USART.SchDoc
8xUSART1_TX
8xUSART2_TX
8xUSART3_TX
8xUSART4_TX
8xUSART5_TX
8xUSART6_TX
8xUSART7_TX
8xUSART8_TX
8xUSART1_RX
8xUSART2_RX
8xUSART3_RX
8xUSART4_RX
8xUSART5_RX
8xUSART6_RX
8xUSART7_RX
8xUSART8_RX
U_LCD_MicroSD
LCD_MicroSD.SchDoc
24Mhz clock
SPI1_SCK
SPI1_MOSI
SPI1_MOSI_DIR
SPI1_MISO_3V3
MicroSD_CS_3V3
LCD_CS_3V3
SDcard_detect
RESET#
U_SWD
SWD.SchDoc
1Mhz clock
SWCLK
SWDAT
RESET#
U_ST_LINK_V2-1
ST_LINK_V2-1.SCHDOC
TCK/SWCLK
TMS/SWDIO
RESET#
STLK_RX
STLK_TX
U_RS232_RS485_IrDA
RS232_RS485_IrDA.SchDoc
USART1_RX_3V3
USART1_TX
USART1_RTS
USART1_CTS_3V3
Bootloader_BOOT0_3V3
Bootloader_RESET_3V3
Title: TOP
Project:
STM32091C-EVAL
Size: A4
Date: 7/25/2014
U_Power
Power.SchDoc
Note1:Draft V0.1
Reference: MB1169 Revision: B.1
Sheet: 1 of 14
