ST STM32091C-EVAL User Manual page 54

Appendix A STM32091C-EVAL IO Assignment
54/58
Table 30. IO assignement (continued)
Pin No.
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
DocID026902 Rev 2
Pin Name STM32091C-EVAL IO Assignment
PC4
PC5
PB0
PB1 or NPOR
PB2 or NPOR
PE7
PE8
PE9
PE10
PE11
PE12
PE13
PE14
PE15
PB10
PB11
VSS_2
VDD_2
PB12
PB13
PB14
PB15
PD8
PD9
PD10
PD11
PD12
PD13
PD14
PD15
PC6
PC7
PC8
PC9
PA8
UM1817
-
-
-
-
SPI1_MOSI_DIR
-
-
-
-
-
-
-
LCD/SD_SPI1_MISO
LCD/SD_SPI1_MOSI
USB_VBUS_detection
-
VSS
VDD
-
HDMI_Sink_I2CX
HDMI_Sink_I2CX
SD_Detection
LED1
LED2
LED3
HDMI_HPD_Sink
TS_CH1
TS_CH2
TS_CAP_G8_IO3
LED4
IR_IN
-
-
-
Smart_CK
